upvcp49
3H INC.
Item No. | upvc inwards opening fireproof window hardware system |
Application | UPVC casement fireproof windows |
Applicable Size | Sash height 550-1700mm, sash width 300-1000mm |
Main material | Stainless steel 304, aluminum alloy |
Finish | Power coating |
Specification
<
<
| No. | Item No. | Item Name | QTY | Remark |
| 1 | PCZ26 | Square shaft handle | 1 | Standard square shaft length:34mm. the screw:M5*50mm |
| 2 | PCQ1505.600.2 | Transmission device | 1 | Center Distance 15mm |
| PCQ1505.800.2 | 1 | |||
| PCQ1505.1000.2 | 1 | |||
| 3 | PSS03 | Lock Block | 3 | / |
| 4 | PFJQ02 | Corner device | 1 | / |
| 5 | PJCZ03D | Middle hinqe | 2 | / |
| 6 | PJCX03CR/L | Bottom hinqe | 1 | / |
| 7 | PFDE01 | Limiter stay | 1 | / |
| 8 | PCG02/400 | Connecting rod | 1 | / |
| 9 | PFTO3 | Elevator block | 1 | / |
| Self-preparation | Temperature controller | 1 | / |
Product Description
This system has the function of automatic locking in case of fire.
The maximum load-bearing capacity of this configuration is 60kg, which is suitable for window sash groove height of 800mm-1300mm.
There are more optional handles.please refer to the Handle Series.
The above accessories is suit for the 9 series profiles.the13 series profile.
The above hardware system is for reference only.Please provide relevant informatlon and contact our technical department.
